Product Summary
The 1.5KE200CA is a 1500 Watt Mosorb Zener Transient Voltage Suppressor. The 1.5KE200CA is designed to protect voltage sensitive components from high voltage, high–energy transients. The 1.5KE200CA has excellent clamping capability, high surge capability, low zener impedance and fast response time. The 1.5KE200CA is an exclusive, cost-effective, highly reliable Surmetic axial leaded package and are ideally-suited for use in communication systems, numerical controls, process controls, medical equipment, business machines, power supplies and many other industrial/ consumer applications, to protect CMOS, MOS and Bipolar integrated circuits.
Parametrics
1.5KE200CA absolute maximum ratings: (1)Peak Power Dissipation (Note 1) @ TL≤25℃ PPK: 1500 Watts; (2)Steady State Power Dissipation @ TL≤75℃,Lead Length = 3/8" : PD 5.0W; (3)Derated above TL = 75℃: 20mW/℃; (4)Thermal Resistance, Junction–to–Lead RθJL: 20℃/W; (5)Operating and Storage Temperature Range TJ, Tstg: –65 to 175℃.
Features
1.5KE200CA features: (1)The features of 1.5KE200CAcan be summarized as (1)Working Peak Reverse Voltage Range -5.8 V to 214 V; (2)Peak Power ?1500 Watts @ 1 ms; (3)ESD Rating of Class 3 (＞16 KV) per Human Body Model; (4)Maximum Clamp Voltage @ Peak Pulse Current; (5)Low Leakage＜5μA above 10 V; (6)UL 497B for Isolated Loop Circuit Protection; (7)Response Time is typically＜1ns.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 1.5KE200CA |
Littelfuse |
TVS Diodes - Transient Voltage Suppressors 1500W 171V Bi-Directional |
Data Sheet |
|
|
||||||||||||
 |
1.5KE200CA/1 |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 1500W 200V 5% Bidir |
Data Sheet |
Negotiable |
|
||||||||||||
|
1.5KE200CA/51 |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 1500W 200V 5% Bidir |
Data Sheet |
Negotiable |
|
||||||||||||
|
1.5KE200CA/54 |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 1500W 200V Bidirect |
Data Sheet |
Negotiable |
|
||||||||||||
|
1.5KE200CA/4 |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 1500W 200V Bidirect |
Data Sheet |
Negotiable |
|
||||||||||||
|
1.5KE200CA/23 |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 1500W 200V Bidirect |
Data Sheet |
Negotiable |
|
||||||||||||
|
1.5KE200CA-B |
Littelfuse |
TVS Diodes - Transient Voltage Suppressors 1500W 171V Bi-Directional |
Data Sheet |
|
|
||||||||||||
|
1.5KE200CA-E3/54 |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 1500W 200V Bidirect |
Data Sheet |
|
|
||||||||||||
