Product Summary

The B140-13-F is a surface mount schottky barrier rectifier.

Parametrics

B140-13-F absolute maximum ratings: (1)Working Peak Reverse Voltage : 40V; (2)RMS Reverse Voltage : 28V; (3)Average Rectified Output Current @TT=130℃ : 1.0A; (4)Non-Repetitive Peak Forward Surge Current 8.3ms Single Half Sine-Wave Superimposed on Rated Load : 30 A.

Features

B140-13-F features: (1)Guard Ring Die Construction for Transient Protection; (2)Ideally Suited for Automated Assembly; (3)Low Power Loss, High Efficiency; (4)Surge Overload Rating to 30A Peak; (5)For Use in Low Voltage, High Frequency Inverters, Free Wheeling, and Polarity Protection Application.

Diagrams

B140-13-F dimension

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
B140-13-F
B140-13-F
Diodes Inc.
Schottky (Diodes & Rectifiers) 40V 1A
Data Sheet
0-1: $0.30
1-10: $0.22
10-100: $0.13
100-250: $0.09
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
B140
B140
Other

Data Sheet
Negotiable
B140-101X
B140-101X

DVI CAT5 EXTENDER KIT
Data Sheet
0-1: $121.30
B140-13
B140-13
Diodes Inc.
Schottky (Diodes & Rectifiers) 40V 1A
Data Sheet
Negotiable
B140-13-F
B140-13-F
Diodes Inc.
Schottky (Diodes & Rectifiers) 40V 1A
Data Sheet
0-1: $0.30
1-10: $0.22
10-100: $0.13
100-250: $0.09
B140AA
B140AA
TE Connectivity
General Purpose / Industrial Relays RELAY
Data Sheet
0-1: $7,238.71
B140AGH
B140AGH
TE Connectivity / P&B
General Purpose / Industrial Relays
Data Sheet
0-1: $12,266.66
