BYG22D-E3/TR

BYG22D-E3/TR, Super Fast Silicon Mesa SMD Rectifier, DO, 2A, 200V, Vishay Telefunken

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.02~0.07 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.02~0.07

PartNumber:: BYG22D-E3/TR

Brand:: Vishay Telefunken - Vishay | Pack: DO | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Iceble's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-09-07

From Other Seller

Part Number:BYG22D-E3/TR
US $0.02 - 0.07
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The BYG22D-E3/TR is a Super Fast Silicon Mesa SMD Rectifier. The applications of the BYG22D-E3/TR include Surface mounting, Super fast rectifier, Freewheeling diodes in SMPS and converters, Snubber diodes.

Parametrics

BYG22D-E3/TR absolute maximum ratings: (1)Reverse voltage =Repetitive peak reverse voltage: 200 V; (2)Peak forward surge current: 35A; (3)Average forward current IFAV: 2A; (4)Junction and storage temperature range Tj=Tstg: –55 to +150℃; (5)Pulse energy in avalanche mode, non repetitive (inductive load switch off): 20mJ.

Features

BYG22D-E3/TR features: (1)Controlled avalanche characteristic; (2)Glass passivated junction; (3)Low reverse current; (4)Low forward voltage; (5)Soft recovery characteristic; (6)Very fast reverse recovery time; (7)Good switching characteristics; (8)Wave and reflow solderable.
