BYM11-800

BYM11-800, surface mount glass passivated junction fast switching rectifier, DO, 1.0A, -65 to +175℃, Vishay Telefunken

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.04~0.09 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.04~0.09

PartNumber:: BYM11-800

Brand:: Vishay Telefunken - Vishay | Pack: DO | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Iceble's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-09-19

From Other Seller

Part Number:BYM11-800
US $0.04 - 0.09
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The BYM11-800 is a surface mount glass passivated junction fast switching rectifier.

Parametrics

BYM11-800 absolute maximum ratings: (1) Polarity color bands (2nd band) : Blue; (2) Maximum repetitive peak reverse voltage : 800V; (3) Maximum RMS voltage : 560V; (4) Maximum DC blocking voltage : 800V; (5) Maximum average forward rectified current at TT = 55℃ : 1.0A; (6) Peak forward surge current 8.3 ms single half sine-wave superimposed on rated load : 30A; (7) Maximum full load reverse current, full cycle average at TA = 55℃ : 50μA; (8) Operating junction and storage temperature range : -65 to +175℃.

Features

BYM11-800 features: (1)Superectifier structure for high reliability condition; (2)Ideal for automated placement; (3)Fast switching for high efficiency; (4)Low leakage current; (5)High forward surge capability; (6)Meets environmental standard MIL-S-19500; (7)Meets MSL level 1, per J-STD-020, LF maximum peak of 250℃; (9)AEC-Q101 qualified; (10)Compliant to RoHS Directive 2002/95/EC and in accordance to WEEE 2002/96/EC.
