GF1D

GF1D, surface mount glass passivated junction rectifier, DO, 200V, 15pF, Vishay Telefunken

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.02~0.07 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.02~0.07

PartNumber:: GF1D

Brand:: Vishay Telefunken - Vishay | Pack: DO | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Iceble's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-09-19

From Other Seller

Part Number:GF1D
US $0.02 - 0.07
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The GF1D is a surface mount glass passivated junction rectifier.

Parametrics

GF1D absolute maximum ratings: (1)Maximum repetitive peak reverse voltage VRRM: 200V; (2)Maximum RMS voltage VRMS: 140V; (3)Maximum DC blocking voltage VDC: 200V; (4)Maximum average forward rectified current at TL=125℃ I(AV): 1.0 Amp; (5)Maximum instantaneous forward voltage at 1.0A VF: 1.10V; (6)Maximum DC reverse current TA=25℃: 5.0μA; (7)at rated DC blocking voltage TA=125℃ IR: 50.0μA; (8)Typical reverse recovery time (NOTE 1) trr: 2.0 ms; (9)Typical junction capacitance (NOTE 2) CJ: 15.0 pF; (10)Typical thermal resistance (NOTE 3) RθJA: 80.0℃/W; (11)Operating junction and storage temperature range TJ, TSTG: -65 to +175℃.

Features

GF1D features: (1)Plastic package has Underwriters Laboratory Flammability Classification 94V-0; (2)Ideal for surface mount automotive applications; (3)High temperature metallurgically bonded construction; (4)Glass passivated cavity-free junction; (5)Capable of meeting environmental standards of MIL-S-19500; (6)Built-in strain relief; (7)Easy pick and place; (8)High temperature soldering guaranteed: 450℃/5 seconds at terminals; (9)Complete device submersible temperature of 265℃ for 10 seconds in solder bath.
