Product Summary

The US1K is a surface mount ultrafast rectifier.

Parametrics

US1K absolute maximum ratings: (1)Maximum Recurrent Peak Reverse Voltaqe : 800V; (2)Maximum RMS Voltaqe : 560V; (3)Maximum DC Blockinq Voltaqe : 800V; (4)Maximum Average Forward Rectified Current, at TL=100℃ : 1.0 A; (5)Peak Forward Surge Current 8.3ms single half sine-wave superimposed on rated load(JEDEC method) TA=55℃ : 30.0 A; (6)Maximum Instantaneous Forward Voltaqe at 1.0A : 1.7V; (7)Maximum DC Reverse Current TA=25℃ : 10.0A; (8)At Rated DC Blocking Voltage TA=100℃ : 100A; (9)Maximum Reverse Recovery Time (Note 1) TJ=25℃ : 100.0 nS; (10)Typical Junction capacitance (Note 2) : 17 pF; (11)Maximum Thermal Resistance (Note 3) : 30°C/W; (12)Operating and Storage Temperature Range : -50 to +150 ℃.

Features

US1K features: (1)For surface mounted app cations; (2)Low profile package; (3)Built-in strain relief; (4)Easy pick and place; (5)Ultrafast recovery times for high efficiency; (6)Plastic package has Underwriters Laboratory; (7)Flammability Classification 94V-O; (8)Glass passivated junction; (9)High temperature soldering : 260 ℃/10 seconds at terminals.
