Product Summary

1 optical and electrical properties of Electrical / Optical characteristics

(1) the maximum value of Absolute Maximum Ratings (TA=25 ± 5 o C)

Project Item symbol

Symbol maximum ratings

Absolute Maximum Rating unit

Unit

Forward current Forward Current IF 30mA

Peak forward current Pulse Forward Current IFP 150mA

Reverse voltage Reverse Voltage VR 9V

Power consumption of Power Dissipation PD 100 mW

Working temperature: Operating Temperature Topr To +85 -40 o C o C ° C

Storage temperature Storage Temperature Tstg To +85 -40 o C o C ° C

Welding temperature of Soldering Temperature Tsld ReflowSoldering:260 o C

Hand Soldering: 350 o C for 10sec. for 3sec.

1/10 cycle, 0.1 msec pulse width

IFP Conditions: 1/10 Duty Cycle, 0.1 msec Pulse Width.
