Product Summary

MAXIMUM RATINGS (TA = 25 °C unless otherwise noted)


PARAMETER
 SYMBOL
 VALUE
 UNIT
Peak pulse power dissipation with a 10/1000 μs waveform (1) (fig. 1)
 PPPM
 600
 W
Peak pulse current with a 10/1000 μs waveform (1)
 IPPM
 See next table
 A
Power dissipation on infinite heatsink at TL = 75 °C (fig. 5)
 PD
 5
 W
Peak forward surge current 8.3 ms single half sine-wave (2)
 IFSM
 100
 A
Maximum instantaneous forward voltage at 50 A for uni-directional only (3)
 VF
 3.5/5.0
 V
Operating junction and storage temperature range
 TJ, TSTG
 - 55 to + 175
 °C
