Product Summary

The 11DQ04 is a Schottky Rectifier. The 11DQ04 has been optimized for very low forward voltage drop, with moderate leakage. Typical applications of the 11DQ04 are in switching power supplies, converters, freewheeling diodes, and reverse battery protection.

Parametrics

11DQ04 absolute maximum ratings: (1)Maximum average forward current: 1.1A; (2)Maximum peak one cycle A non-repetitive surge current: 225A; (3)Non-repetitive avalanche energy: 3mJ; (4)Repetitive avalanche current: 1A.

Features

11DQ04 features: (1)Low profile, axial leaded outline; (2)High frequency operation; (3)Very low forward voltage drop; (4)High purity, high temperature epoxy encapsulation for enhanced mechanical strength and moisture resistance; (5)Guard ring for enhanced ruggedness and long term reliability; (6)Lead (Pb)-free plating; (7)Designed and qualified for industrial level.

Diagrams

11DQ04 Pin configuration

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
11DQ04
11DQ04

DIODE SCHOTTKY 40V 1.1A DO-41
