Product Summary

The ES2D is a fast rectifier.

Parametrics

ES2D absolute maximum ratings: (1)VRRM Maximum Repetitive Reverse Voltage: 200 V; (2)IF(AV) Average Rectified Forward Current .375 " lead length @ TA = 110℃: 2.0A; (3)IFSM Non-repetitive Peak Forward Surge Current 8.3 ms Single Half-Sine-Wave: 50A; (4)Tstg Storage Temperature Range: -55 to +150℃; (5)TJ Operating Junction Temperature: -55 to +150℃.

Features

ES2D features: (1)For surface mount applications; (2)Glass passivated junction; (3)Low profile package; (4)Easy pick and place; (5)Built-in strain relief; (6)Superfast recovery times for high efficiency.

Diagrams

ES2D block diagram
