Product Summary

The MBR0520LT1G is a surface mount schottky power rectifier. The MBR0520LT1G employs the Schottky Barrier principle with a barrier metal that produces optimal forward voltage drop−reverse current tradeoff. The MBR0520LT1G is ideally suited for low voltage, high frequency rectification, or as free wheeling and polarity protection diodes in surface mount applications where compact size and weight are critical to the system. This package provides an alternative to the leadless 34 MELF style package.

Parametrics

MBR0520LT1G absolute maximum ratings: (1) Peak Repetitive Reverse Voltage : 20V; (2) Average Rectified Forward Current (Rated VR, TL = 90℃) : 0.5A; (3) Non−Repetitive Peak Surge Current (Surge Applied at Rated Load Conditions Halfwave, Single Phase, 60 Hz) : 5.5A; (4) Storage Temperature Range : -65 to +150℃; (5) Operating Junction Temperature : -65 to +125℃; (6) Voltage Rate of Change (Rated VR) : 1000V/μs.

Features

MBR0520LT1G features: (1)Guardring for Stress Protection; (2)Very Low Forward Voltage (0.38 V Max@0.5 A, 25℃); (3)125℃ Operating Junction Temperature; (4)Epoxy Meets UL 94 V-0@0.125 in; (5)Package Designed for Optimal Automated Board Assembly; (6)Pb-Free Packages are Available.
