Product Summary

The BB689-02VE7902 is a Silicon Tuning Diode.

Parametrics

BB689-02VE7902 absolute maximum ratings: (1)Diode reverse voltage VR: 30V; (2)Peak reverse voltage( R≤5kΩ) VRM 35V; (3)Forward current IF: 20mA; (4)Operating temperature range Top: -55 to 150℃; (5)Storage temperature Tstg: -55 to 150℃.

Features

BB689-02VE7902 features: (1)For VHF 2-Band-hyperband-TV-tuners; (2)Very high capacitance ratio; (3)Low series resistance; (4)Excellent uniformity and matching due to "in-line" matching assembly procedure.

Diagrams

BB689-02VE7902 Pin Configuration

BB689
BB689
